Key features

• •1
• •9
• •8
• •4
• •-
• •3.2 liter (930/21 and 930/25)
• •915 (5-speed, with cable-operated clutch)
• •G50 (5-speed, with hydraulic clutch)
• •911 Carrera Coupe
• •911 Carrera Targa
• •911 Carrera Cabriolet
• •Maintenance procedures for everything from changing the oil in the dry-sump lubrication system to adjusting front wheel bearing play. This manual tells you what to do and how and when to do it.
• •Illustrated engine disassembly and rebuilding, including camshaft, timing chain, and timing chain tensioner replacement with the engine in or out of the car.
• •Dry-sump lubrication system repair and diagnosis, including replacing leaky oil return tubes with the engine installed.
• •Carrera-specific driveability problems, including explanation of the Bosch DME engine management system.
• •Complete overhaul of the 915 transmission, including replacing the synchronizer "dog" teeth.
• •Complete clutch service, including clutch cable replacement (1984-1986 models) and clutch hydraulics service (1987 1989 models).
• •Brake, steering and suspension system maintenance, troubleshooting, and repair, including torsion bar setup and adjustment.
• •Heating and air conditioning repair, including A/C component replacement.
• •Body adjustments and repairs, including power seat disassembly and repair.
• •Electrical system diagnosis and fault finding, with an easy-to-use illustrated component locator section.
• •Wiring schematics for all circuits, including power distribution, grounds, convertible top, rear wiper and other hard to find circuits.
