Key features

• •The ProD8 direct box is a high performance 8-channel passive direct box optimized for keyboard rigs in professional touring, with redundant 1/4″ inputs for each channel and a completely passive design that requires no power to operate. The Radial ProD8 offers superior performance at an affordable price and are ideally suited for use with acoustic guitar bass and keyboards INCLUDED 2 x Senor Guitar Instrument Cable 2 x Senor Microphone Cable and Zorro Sounds Instrument Polishing Cloth
• •The ProD8 is a high-density rackmountable 8-channel direct box that is specifically designed to interface keyboards and pre-recorded backing tracks to the PA system with redundant inputs for live performance back-up. The ProD8's input panel is equipped with two A-B 1/4" inputs per DI channel for main and back-up sources, throughput for personal monitoring and an effects loop that allows both A-B sources to share the same effects for each channel
• •The ProD8 direct box employs eight custom wound Radial transformers that are linear from 20Hz to 18kHz and able to withstand highly dynamic levels from sources such as digital samplers and drum machines without flinching. To reduce interference from outside magnetic fields, the transformers are equipped with a mu-metal-nickel outer shield thus reducing phase distortion to an absolute minimum
• •The Passive direct box Radial ProD8 features a reversible set of rack ears that allows the1/4" input panel or the XLR output panels to be position at the front or back, depending on the system engineers preference.The output panel features a XLR connector, -15dB input pad selector and ground lift witch. A 180 degree polarity reverse switch is internally mounted and factory set with pin 2 hot.
• •Adaptable Configuration - To enhance setup options, the Radial ProD8 is equipped with reversible rack ears. This handy feature allows the system tech to position the inputs on the front of the rack when interfacing with external keyboards or have them inside if the setup is predominantly equipped with rack modules.
