Key features

• •All metal chassis provides a rugged and durable construction
• •Buffers USB data from any attached peripheral in compliance with USB specifications.
• •Designed to provide quick and easy access, can be powered with a three wire terminal block connector (9-48V) with AC Adapter Required, the AC adapter is sold separately
• •Supports low speed (1.5Mbps and 12Mbps), Hi-Speed (480Mbps), and Super-Speed (5,000 Mbps) devices
• •The all metal chassis provides a rugged and durable construction that can withstand operating conditions in both the Automotive and Marine industries.
• •LEDs provide port and power status.
• •Compliant with USB Specification Revision 3.0
• •Backwards compatible with USB Specification Revisions 2.0 / 1.1
• •Supports High-speed and or Full-speed Packet
• •Protocol Sequencer for Endpoint 0/1
• •Provides 12 Downstream Facing USB 3.0 Ports
• •Supports 5,000Mbps, 480Mbps, 12Mbps and 1.5Mbps Speed
• •Multi Transaction Translator per Hub and Supports 12 Concurrent Non-periodic Transactions
• •Supports Self-powered Mode
• •Supports Downstream Port Status with LED
• •High-speed or Full-speed Packet Protocol Sequencer for Endpoint 0/1
• •Dimensions: 5.132in(L) (6.132in w/flange) x 2.608in(W) x 2.104in(H)
• •Hub Weight: .887 lbs.
• •Supports 12 external USB 3.0 Type-A connectors and 1 Type-B Upstream connector.
• •Supports a 3-pin Terminal Block Connector for external power input from AC adapter (Not included)
• •Operating Temp.: 0 to 55C (32 to 131 F)
• •Storage Temp: -20C to 85C (-4 to 185 F)
• •Operating Humidity: 5 to 95% RH
