Key features

• •EG8010 is a digital, function very well bring their own dead-time control of pure sine wave inverter generator chip, used in two-stage DC-DC-AC power conversion structure or single-stage DC-AC power frequency transformer Boost architecture, an external 12MHz crystal oscillator, to achieve high precision, and harmonic distortion is very small, 50Hz or 60Hz pure sine wave inverter ASIC.
• •The chip uses CMOS technology, the internal integration of SPWM sine generator, dead time control circuit, the multiplier factor range, soft start circuit, protection circuit, RS232 serial communication interface and a serial LCD driver module 1602 functions.
• •Pin set 4 kinds of pure sine wave output frequency: 50Hz pure sine wave fixed frequency, 60Hz pure sine wave fixed frequency, 0-100Hz pure sine wave frequency adjustable, 0-400Hz pure sine wave frequency adjustable.
• •Applications: Single-phase pure sine wave inverters, PV inverters, wind power inverters, uninterruptible power supply UPS systems, digital generator systems, frequency power supply, single-phase motor speed controller, a single-phase inverter, sine wave dimmers, sine wave voltage regulator, sine wave generator
