Key features

• •❤EG8010 is a digital, function very well bring their own dead-time control of pure sine wave inverter generator chip, used in two-stage DC-DC-AC power conversion structure or single-stage DC-AC power frequency transformer Boost architecture, an external 12MHz crystal oscillator, to achieve high precision, and harmonic distortion is very small, 50Hz or 60Hz pure sine wave inverter ASIC.
• •❤The chip uses CMOS technology, the internal integration of SPWM sine generator, dead time control circuit, the multiplier factor range, soft start circuit, protection circuit, RS232 serial communication interface and a serial LCD driver module 1602 functions.
• •❤Voltage,current,real time temperature feedback;Overvoltage,undervoltage,overcurrent and overheating protection;Serial communication to set the output voltage,frequency and other parameters External
• •❤Comes with deadband control,pin set up 4 dead time:300nS dead time;500nS dead time;1.0uS dead time;1.5uS dead time
• •❤Pin set up four kinds of pure sine wave output frequency:fixed frequency 50 hz pure sine wave;60 hz fixed frequency pure sine wave;0-100 hz pure sine wave frequency is adjustable;0-400 hz pure sine wave frequency is adjustable.
